This kind of insulation tube pipe is made by NBR PVC

This kind of insulation tube / pipe is made by NBR/PVC. The tube foam is made by special craft foam and feels very soft. We can supply rubber foam products according to clients’ specific requirements in terms of shapes, colors, hardness levels and other features.

Nominal wall thicknesses of 1/4”, 3/8″, 1/2″, 3/4″,1″, 1-1/4”, 1-1/2″ and 2” (6, 9, 13, 19, 25 , 32, 40 and 50mm).
Standard Length with 6ft (1.83m) or 6.2ft(2m).

Send email to us

Product Detail

Product Tags

Product Description：

Kingflex rubber foam products of our company are produced by imported high-end technology and automatic continuous equipment. We have developed a rubber foam insulation material with excellent performance through in-depth research. The major materials we use are NBR/PVC.

Technical Data Sheet

Kingflex Technical Data
Property	Unit	Value	Test Method
Temperature range	°C	(-50 - 110)	GB/T 17794-1999
Density range	Kg/m3	45-65Kg/m3	ASTM D1667
Water vapor permeability	Kg/(m.s.pa)	≤0.91×10 ﹣¹³	DIN 52 615 BS 4370 Part 2 1973
μ	-	≥10000
Thermal Conductivity	W/(m.k)	≤0.030 (-20°C)	ASTM C 518
		≤0.032 (0°C)
		≤0.036 (40°C)
Fire Rating	-	Class 0 & Class 1	BS 476 Part 6 part 7
Flame Spread and Smoke Developed Index		25/50	ASTM E 84
Oxygen Index		≥36	GB/T 2406,ISO4589
Water Absorption,%by Volume	%	20%	ASTM C 209
Dimension Stability		≤5	ASTM C534
Fungi resistance	-	Good	ASTM 21
Ozone resistance		Good	GB/T 7762-1987
Resistance to U.V. and weather		Good	ASTM G23

Advantages of product

1.Splendid Surface
Nitron-Bubble NBR/PVC insulation material has flat and even surface without abvious goffer. Under pressure, it appears symmetrical skin-like wrinkle, which takes on noble and top grade quality.

2. Excellent OI Critical Value
Nitron-Bubble NBR/PVC insulation material requires high oxygen index, which makes it great fireproof capability.

3. Outstanding Smoke Density Class
Nitron-Bubble NBR/PVC insulation material has quite low smoke density class as well as low smog thickness, which provide good action when it is burning.

4. Agelong Life In Heat Conductivity Value (K-Value)
Nitron-Bubble NBR/PVC insulation material has long-term, stable K-value, which guarantee long life span of the products.

5. High Moisture Resistance Factor (u-Value)
Nitron-Bubble NBR/PVC insulation material has high moisture resistance factor, u≥15000, which makes it a strong ability in anti-condensation.

6. Firm Performance in Temperature and Anti-Aging
Nitron-Bubble NBR/PVC insulation material has excellent capability in anti-ozone, anti-insolation and anti-ultraviolet, which ensures long life span.
