Kingflex Closed Cell Rubber Foam Sheet Roll With Self-Adhesive
Description
Kingflex rubber foam sheet with self-adhesive widely used in electrical cabinets, cars, speakers, toys, handicrafts, sports equipment, etc. The adhesive foam pads are made from high-quality neoprene closed-cell foam. Resistant to high and low temperatures, can be used from -50℃ to 110℃. Weatherproof, oil resistance, resistant to corrosion, dust proof, buffering, flame retardant, shock-absorbing, sound and heat insulation, anti-skidding, and insulating.
Standard Dimension
|
Kingflex Dimension |
|||||||
|
Thickness |
Width 1m |
Width 1.2m |
Width 1.5m |
||||
|
Inches |
mm |
Size(L*W) |
㎡/Roll |
Size(L*W) |
㎡/Roll |
Size(L*W) |
㎡/Roll |
|
1/4" |
6 |
30 × 1 |
30 |
30 × 1.2 |
36 |
30 × 1.5 |
45 |
|
3/8" |
10 |
20 × 1 |
20 |
20 × 1.2 |
24 |
20 × 1.5 |
30 |
|
1/2" |
13 |
15 × 1 |
15 |
15 × 1.2 |
18 |
15 × 1.5 |
22.5 |
|
3/4" |
19 |
10 × 1 |
10 |
10 × 1.2 |
12 |
10 × 1.5 |
15 |
|
1" |
25 |
8 × 1 |
8 |
8 × 1.2 |
9.6 |
8 × 1.5 |
12 |
|
1 1/4" |
32 |
6 × 1 |
6 |
6 × 1.2 |
7.2 |
6 × 1.5 |
9 |
|
1 1/2" |
40 |
5 × 1 |
5 |
5 × 1.2 |
6 |
5 × 1.5 |
7.5 |
|
2" |
50 |
4 × 1 |
4 |
4 × 1.2 |
4.8 |
4 × 1.5 |
6 |
Technical Data Sheet
|
Kingflex Technical Data |
|||
|
Property |
Unit |
Value |
Test Method |
|
Temperature range |
°C |
(-50 - 110) |
GB/T 17794-1999 |
|
Density range |
Kg/m3 |
45-65Kg/m3 |
ASTM D1667 |
|
Water vapor permeability |
Kg/(m.s.pa) |
≤0.91×10 ﹣¹³ |
DIN 52 615 BS 4370 Part 2 1973 |
|
μ |
- |
≥10000 |
|
|
Thermal Conductivity |
W/(m.k) |
≤0.030 (-20°C) |
ASTM C 518 |
|
≤0.032 (0°C) |
|||
|
≤0.036 (40°C) |
|||
|
Fire Rating |
- |
Class 0 & Class 1 |
BS 476 Part 6 part 7 |
|
Flame Spread and Smoke Developed Index |
|
25/50 |
ASTM E 84 |
|
Oxygen Index |
|
≥36 |
GB/T 2406,ISO4589 |
|
Water Absorption,%by Volume |
% |
20% |
ASTM C 209 |
|
Dimension Stability |
|
≤5 |
ASTM C534 |
|
Fungi resistance |
- |
Good |
ASTM 21 |
|
Ozone resistance |
Good |
GB/T 7762-1987 |
|
|
Resistance to U.V. and weather |
Good |
ASTM G23 |
|
Application
Kingflex rubber foam roll with self-adhesive has good adhesion: The adhesive foam sheet has a strong adhesive backing, waterproof and non-degumming, and sticks firmly, is an ideal solution for gaskets and insulation projects. The neoprene foam rubber pad can be easily cut into different shapes and sizes. Just use scissors to trim it to a perfect fit.
