Kingflex Closed Cell Elastomeric NBR Foam Rolls
Description
Kingflex rubber foam insulation material is soft heat-insulating, heat-preservation and energy conservation materials made with advanced technology and advanced full-automatic continuous production line imported from abroad,using polyvinyl Chloride (NBR,PVC) as main raw materials and other high quality auxiliary materials through foaming and so on special procedure.
Standard Dimension
|
Kingflex Dimension |
|||||||
|
Thickness |
Width 1m |
Width 1.2m |
Width 1.5m |
||||
|
Inches |
mm |
Size(L*W) |
㎡/Roll |
Size(L*W) |
㎡/Roll |
Size(L*W) |
㎡/Roll |
|
1/4" |
6 |
30 × 1 |
30 |
30 × 1.2 |
36 |
30 × 1.5 |
45 |
|
3/8" |
10 |
20 × 1 |
20 |
20 × 1.2 |
24 |
20 × 1.5 |
30 |
|
1/2" |
13 |
15 × 1 |
15 |
15 × 1.2 |
18 |
15 × 1.5 |
22.5 |
|
3/4" |
19 |
10 × 1 |
10 |
10 × 1.2 |
12 |
10 × 1.5 |
15 |
|
1" |
25 |
8 × 1 |
8 |
8 × 1.2 |
9.6 |
8 × 1.5 |
12 |
|
1 1/4" |
32 |
6 × 1 |
6 |
6 × 1.2 |
7.2 |
6 × 1.5 |
9 |
|
1 1/2" |
40 |
5 × 1 |
5 |
5 × 1.2 |
6 |
5 × 1.5 |
7.5 |
|
2" |
50 |
4 × 1 |
4 |
4 × 1.2 |
4.8 |
4 × 1.5 |
6 |
Technical Data Sheet
|
Kingflex Technical Data |
|||
|
Property |
Unit |
Value |
Test Method |
|
Temperature range |
°C |
(-50 - 110) |
GB/T 17794-1999 |
|
Density range |
Kg/m3 |
45-65Kg/m3 |
ASTM D1667 |
|
Water vapor permeability |
Kg/(m.s.pa) |
≤0.91×10 ﹣¹³ |
DIN 52 615 BS 4370 Part 2 1973 |
|
μ |
- |
≥10000 |
|
|
Thermal Conductivity |
W/(m.k) |
≤0.030 (-20°C) |
ASTM C 518 |
|
≤0.032 (0°C) |
|||
|
≤0.036 (40°C) |
|||
|
Fire Rating |
- |
Class 0 & Class 1 |
BS 476 Part 6 part 7 |
|
Flame Spread and Smoke Developed Index |
|
25/50 |
ASTM E 84 |
|
Oxygen Index |
|
≥36 |
GB/T 2406,ISO4589 |
|
Water Absorption,%by Volume |
% |
20% |
ASTM C 209 |
|
Dimension Stability |
|
≤5 |
ASTM C534 |
|
Fungi resistance |
- |
Good |
ASTM 21 |
|
Ozone resistance |
Good |
GB/T 7762-1987 |
|
|
Resistance to U.V. and weather |
Good |
ASTM G23 |
|
Advantages of product
1. The product is inflammable and has high safety performance.
2. Flexible material, suitable for various shapes and easy installation
3. The closed cell structure prevents the penetration of water vapor and prolongs the service life.
